RED V-RAPTOR XL [X] – 8K VV

R1,000,000.00

Key Features

V-RAPTOR XL 8K [X] VV Camera
RED Touch 7.0″ LCD, Rigid Hinge, Shade
2 x RED PRO CFexpress 2TB Cards, Reader
V-RAPTOR XL Top Handle with Extensions
V-RAPTOR XL Riser Plate
V-RAPTOR XL Top/Bottom 15mm LWS Brackets
DSMC3 RED 5-Pin to Dual-XLR Adapter
18″ DSMC3 RMI Cable
Requires Separately Available Batteries

SKU: N/A Categories: Broadcast, Cinema Tags: RED, RED Cinema

Description

RED V-RAPTOR XL [X] – 8K VV Global Shutter Studio & Production Cinema Camera

The RED V-RAPTOR XL [X] represents the pinnacle of RED’s large-format cinema lineup, purpose-built for high-end feature films, broadcast studios, virtual production stages, and demanding commercial environments. Integrating RED’s next-generation 8K Vista Vision global shutter sensor within an expanded, production-ready XL body, this system combines uncompromising image performance with professional I/O, advanced power distribution, and seamless studio integration.

8K Vista Vision Global Shutter Sensor:
At the core of the V-RAPTOR XL [X] is RED’s advanced 8K VV global shutter CMOS sensor, eliminating rolling shutter artifacts while maintaining exceptional dynamic range and highlight detail. Capture ultra-high-resolution imagery with cinematic depth, refined tonal roll-off, and robust color science designed for premium theatrical and streaming delivery.

Integrated ND & Studio-Ready Architecture:
The XL platform incorporates built-in electronic ND filters for precise exposure control without external filtration. Its expanded body design integrates professional connectivity and power management, reducing rig complexity and improving reliability in studio, broadcast, and virtual production pipelines.

REDCODE® RAW & High Frame Rates:
Record in REDCODE RAW with adjustable compression settings, offering maximum latitude for grading and VFX workflows. The V-RAPTOR XL [X] supports high frame rates across multiple resolutions, enabling slow-motion capture without sacrificing image integrity.

Professional I/O & Broadcast Connectivity:
Designed for large-scale production environments, the camera features advanced I/O including multiple 12G-SDI outputs, timecode, genlock, Ethernet/IP control, and integrated power distribution. These features support multi-camera synchronization, LED wall workflows, and complex studio configurations.

Expanded XL Form Factor:
The XL body enhances durability and workflow efficiency with a robust, modular chassis that integrates seamlessly with professional cinema rigs, studio pedestals, cranes, dollies, and broadcast mounts. Built-in power distribution simplifies accessory integration while maintaining a clean, production-ready footprint.

Key Features:

8K VV Global Shutter Sensor: Large-format capture with zero rolling shutter
Integrated Electronic ND: Seamless in-camera exposure control
REDCODE RAW Recording: Flexible compression for advanced post workflows
Professional Studio I/O: Multiple 12G-SDI, genlock, timecode, IP control
Integrated Power Distribution: Streamlined accessory and rig management
XL Production Body: Engineered for studio, broadcast, and virtual production

The RED V-RAPTOR XL [X] is a top-tier large-format cinema system that combines 8K global shutter imaging, integrated ND control, and professional broadcast connectivity in a refined, studio-ready platform built for the most demanding productions.

View More RED DIGITAL CINEMA PRODUCTS Here

Additional information

SELECT KIT	V-LOCK, PRODUCTION PACK (V-LOCK)

Specifications

Lens Mount	Interchangeable Mount
Image Sensor	VistaVision
Effective Sensor Resolution	35.4 Megapixel (8192 x 4320)
Image Stabilization	No
Max Recording Modes	REDCODE RAW Up to DCI 8K up to 120 fps REDCODE HQ/REDCODE LQ/REDCODE MQ Up to DCI 8K up to 59.94 fps
Max Video Output	Up to DCI 4K up to 60.00 fps
Media/Memory Card Slot	Single Slot: CFexpress Type B (CFast 2.0)
Video I/O	3x BNC (12G-SDI) Output 1x BNC (3G-SDI) Output 1x Proprietary Output
Mobile App Compatible	Yes: Android & iOS
Battery	V-Mount

Imaging

Lens Mount	Interchangeable Mount
Lens Communication	Yes
Image Sensor	40.96 x 21.6 mm (VistaVision) CMOS
Effective Sensor Resolution	35.4 Megapixel (8192 x 4320)
Image Stabilization	No
Built-In ND Filter	Mechanical Filter Wheel with Clear, 2-Stop (1/4), 3-Stop (1/8), 4-Stop (1/16), 5-Stop (1/32), 6-Stop (1/64), 7-Stop (1/128) ND Filters
Built-In CC Filter	No
Internal Filter Holder	No
Capture Type	Video Only

Exposure Control

Shutter Type	Electronic Global Shutter
Advertised Dynamic Range	17 Stops

Focus

Focus Mode

Automatic, Continuous-Servo AF, Manual Focus, Single-Servo AF

Video Capture

Internal Recording	REDCODE RAW 8192 x 4320 up to 120 fps 7168 x 3780 up to 140 fps* 8192 x 3456 up to 150 fps 6144 x 3240 up to 160 fps* 7168 x 3024 up to 175 fps* 5120 x 2700 up to 192 fps* 6144 x 2592 up to 200 fps* 5120 x 2160 up to 240 fps* 4096 x 2160 up to 240 fps* 4096 x 1728 up to 300 fps* 3072 x 1620 up to 320 fps* 3072 x 1296 up to 400 fps* 2048 x 1080 up to 480 fps* 2048 x 864 up to 600 fps* Sensor Crops During Recording REDCODE HQ/REDCODE LQ/REDCODE MQ* 8192 x 4320 up to 59.94 fps 6144 x 3240 up to 96 fps* 4096 x 2160 up to 240 fps* 2048 x 1080 up to 480 fps*
Video Output	4096 x 2160 up to 60.00 fps 2048 x 1080 up to 60.00 fps
Fast-/Slow-Motion Support	Yes
Gamma Curve	RED IPP2
Built-In Microphone	Mono
Audio Recording	2-Channel, 24-Bit at 48 kHz

Interface

Media/Memory Card Slot	Single Slot: CFexpress Type B (CFast 2.0)
Internal Storage	No
Video I/O	3x BNC (12G-SDI) Output 1x BNC (3G-SDI) Output 1x Proprietary Output
Audio I/O	1x 1/8″ / 3.5 mm TRS Stereo Headphone Output 1x 5-Pin LEMO Mic/Line Input (+48 V Phantom Power)
Power I/O	1x LEMO 4-Pin (19.5 to 34VDC) Input 2x D-Tap (12VDC up to 3 A) Output 1x LEMO 2-Pin (12VDC at 3 A) Output 1x LEMO 2-Pin (12VDC at 1.5 A) Output 1x LEMO 2-Pin (12VDC at 1 A) Output 2x Fischer 3-Pin (12VDC up to 3 A) Output
Other I/O	1x BNC (Genlock) 1x LEMO 5-Pin (Timecode) 1x 9-Pin (Ethernet) Control/Data Input/Output 1x USB-C
Wireless	Wi-Fi
Mobile App Compatible	Yes: Android & iOS App Name: RED Control, RED Control Pro
Global Positioning (GPS, GLONASS, etc.)	No

Monitor

Display Type

Primary Monitor: Fixed 2.4″ Non-Touchscreen LCD

Viewfinder

Type	Support via Video Out Only

Power

Battery

V-Mount

Environmental

Operating Conditions	32 to 104°F / 0 to 40°C
Storage Conditions	-4 to 122°F / -20 to 50°C up to 85% Humidity

General

Tripod Mount	3x 3/8″-16 Female 3x 1/4″-20 Female
Accessory Mounting Thread	34x 1/4″-20 2x ARRI/Hirth Rosette
Netflix Approved	Yes
Materials	Aluminum
Dimensions (W x H x D)	7.9 x 6.5 x 6″ / 200.7 x 165.1 x 152.4 mm
Weight	7.99 lb / 3.62 kg (Body Only)

Packaging Info

Package Weight	16.165 lb
Box Dimensions (LxWxH)	17 x 11.7 x 11″

What's In The Box (V-Lock)

1x V-RAPTOR XL [X] 8K VV (V-Lock) Body
1x V-RAPTOR XL PL Mount
1x RED PL Mount Shim Pack
1x RED AC Power Adaptor 270W
NOTE: POWER CORD NOT INCLUDED – MUST PURCHASE SEPARATELY.
1x 3-Pin XLR-to-4-Pin 2B Power Cable (10′)
RED Logo Sticker
V-RAPTOR XL [X] Information Card (incl. registration and support info)
2 Year Standard Warranty

What's In The Box (Production Pack [V-Lock])

1x V-RAPTOR XL [X] 8K VV Camera System
– NOTE: POWER CORD NOT INCLUDED – MUST PURCHASE SEPARATELY.
1x DSMC3 RED Touch 7” LCD
1x DSMC3 RED Touch 7.0″ LCD Hood
1x DSMC3 RMI Cable 18″
2x RED PRO CFexpress v4 Type B 2TB
1x RED PRO CFexpress v4 Type B Card Reader
4x BATTERIES
1x Compact Dual V-Lock Charger
NOTE: POWER CORD NOT INCLUDED – MUST PURCHASE SEPARATELY.
1x DSMC3 RED 5-Pin to Dual XLR Adapter
1x V-RAPTOR XL Top Handle w/ Extensions
1x V-RAPTOR XL Top 15mm LWS Rod Support Bracket
1x V-RAPTOR XL Bottom 15mm LWS Rod Support Bracket
1x V-RAPTOR XL Riser Plate
2 Year Standard Warranty (camera only)
